Memphis Audio PRX1224

Rolling thunder

Memphis Audio built their Power Reference Series subwoofers to bring strong low-frequency punch into your vehicle. The PRX1224 12″ subwoofer delivers big bass and high output, with a heavy-duty suspension that allows this sub to handle up to 300 watts RMS.

Easy to set up, easy to love

This Power Reference Series subwoofer is built to dish it out and take it. Its treated paper cone and double-stitched butyl rubber surround pump out the lows with toughness and precision. Improvements to the coil and suspension design give you even more of that great Memphis sound. Selectable Impedance Technology allows you to select 2- or 4-ohm impedance using the included color-coded jumpers, making adjustments dead easy and giving you a wide range of installation and system options.

Do you hear a rumble in the distance? That’s the bass you’ve been waiting for on its way to you from Memphis Audio.

Product highlights:

• 12″ component subwoofer
• selectable 2- or 4-ohm impedance
• treated paper cone with double-stitched butyl rubber surround
• power handling: 300 watts RMS (600 watts peak)
• sensitivity: 85.8 dB
• frequency response: 30-150 Hz
• top-mount depth: 5.46″
• cutout diameter: 11″
• sealed box volume: 1.25 cubic feet
• ported box volume: 2.75 cubic feet
• grille not included
• warranty: 1 year
• 60-day returns
• MFR # PRX1224
• Item # 953PRX1224

What’s in the box:

If you need assistance accessing this owner’s manual, please give us a call.

• One 12″ Subwoofer
• Rubber trim ring/gasket (installed)
• One 4-ohm jumper wire (installed)
• Two 2-ohm jumper wires
• Specification sheet
• Warranty information
